Download: HKB01 High-Speed Barrier Gate Technical Specifications
Product Features
- High Efficiency & Durability: Equipped with a two-stage gear motor and Brushless DC technology, ensuring over 10 million operation cycles.
- Intelligent Speed Control: Adjustable lifting speed from 0.6 to 6 seconds. Features automatic deceleration if the barrier descends too fast for enhanced safety.
- Versatile Operation: Supports remote control, manual switch, and fully automatic control modes.
- Reliable Safety System: Built-in overload and thermal protection. The system automatically recovers its last position after a power restoration.
- Wide Compatibility: Features an RS485 communication interface for seamless integration with external security devices.
- Weather Resistant: IP54 protection rating with a robust SPCC Phosphor Steel enclosure and spray coating.
| Parameter | Specification |
|---|---|
| Motor Type | Brushless DC (BLDC) |
| Lifting Speed | 0.6 – 6 seconds (Adjustable) |
| Motor Power | 240W |
| Input Voltage | AC200V ~ 240V |
| Barrier Arm Length | Straight rod ≤ 4 meters |
| Available Rod Types | Aluminum foam arm, Carbon foam arm |
| Operating Temperature | -35°C to 80°C |
| Protection Level | IP54 |
| Communication Interface | RS485 / Switch signal input |
| Enclosure Material | SPCC Phosphor Steel with Spray Coating |
| Dimensions | 295 * 350 * 1060mm |
| Service Life | > 10 Million Cycles |
